Description
- Gas Pressure Regulator
- Type Lock-Up, Balanced Valve
- Nominal Size 3 Inch
- End Connection Female Threaded x Female Threaded
- End to End Distance 10.4 Inch
- Body Material Aluminum
- Temperature Rating -40 to 200 Deg F
- Pressure Rating 10 PSI (Inlet), 25 PSI (Emergency Exposure Limit)
- Application Gas Fired Boiler, Steam Generator, Industrial Furnace and Oven
- Applicable Standard UL, CSA (Canada and US), CE, ANSI Z21.18
- Gas Type Natural, Mixed Gas, Liquefied Petroleum Gas and LP Gas Air Mixture
- Vent Pipe Connection 3/4 Inch Threaded
- Swing Radius 11.9 Inch
- Size 13.4 Inch Width x 16.1 Inch Height
- Pressure Drop Rating 30000 BTU / Hour
