Description
- Switching Relay
- Item Switching Relay
- Type 6-Zone
- Actuation Type Electronic
- Switch Type DPDT
- Overall Dimensions 12-1/4 Inch Width x 3 Inch Depth x 8 Inch Height
- Current Rating 20 Amp (Combined Load), 6 Amp (Full Load) and 36 Amp (Locked Rotor)
- Input Supply Rating 1/3 HP, 120 Volt AC at 60 Hertz 1-Phase
- Inclusions / Features External Indicator Light, Switchable Priority, Simplified Wiring, Fully Enclosed Snap-Out Relay, Compact Design, Fuse Protected, 24 Volt AC 1 Amp Isolated End Switch, Contractor Friendly PC Board Layout, 24 Volt AC Class 2 Universal Thermostat Compatibility, 24 Volt Power Input / Output Terminal
- Application Boiler, Circulator, Hydronic System
- Applicable Standard UL, CSA
- Enclosure Rating NEMA 1
